Automating Tasks

	If you perform a task repeatedly, you can take advantage of a macro to automate it. A macro is a series of functions, written in a scripting language, that you group in a single command to perform the requested task automatically.
	This task will show you how to edit a macro created in the DMU Optimizer workbench.
	Open the ThicknessMacro.CATScript from the sample folder with a Text editor You stored your recorded macros in a text format file. For more details about recording, running macros refer to the DMU Navigator Infrastructure User's Guide.
	You can easily modify the macro instructions specific to DMU Optimizer (strings of characters put in bold). Here is an example: Thickness Macro
	THICKNESS MACRO	EXPLANATIONS
	`Language="VBSCRIPT" Sub CATMain()` `Dim productDocument1 As Document Set productDocument1 = CATIA.ActiveDocument` `Dim dMOThicknesses1 As DMOThicknesses Set dMOThicknesses1 = optimizerWorkBench1.Thicknesses` `Dim product1 As Product Set product1 = productDocument1.Product` `Dim groups1 As AnyObject Set groups1 = product1.GetTechnologicalObject("Groups")`
	`Dim group1 As Group Set group1 = groups1.Add() group1.AddExplicit product1` `Dim dMOThicknesses1 As AnyObject Set dMOThicknesses1 = product1.GetTechnologicalObject("Thicknesses")`	Name of the product selected for the thickness. Enter a meaningful name if you wish to edit the name.


	Dim arrayOfVariantOfDouble1(5) arrayOfVariantOfDouble1(0) = 1665.173462 arrayOfVariantOfDouble1(1) = -682.007568 arrayOfVariantOfDouble1(2) = -29.914585 arrayOfVariantOfDouble1(3) = -0.006795 arrayOfVariantOfDouble1(4) = -0.173679 arrayOfVariantOfDouble1(5) = 0.984779 Dim document1 As Document Set document1 = dMOThicknesses1.ComputeAThickness(group1, 2.000000, -2.000000, 0, arrayOfVariantOfDouble1) Dim optimizerWorkBench1 As Workbench Set optimizerWorkBench1 = productDocument1.GetWorkbench("OptimizerWorkBench") `groups1.Remove group1 document1.Activate`	`2.000000, -2.000000, Gives the values of the offset 1 and offset 2, you defined.`

		`1 corresponds to the number orientation constraints. arrayOfVariantOfDouble1: defines the constraint coordinates:` `Constraint location point` `arrayOfVariantOfDouble1(0) = 1665.173462 arrayOfVariantOfDouble1(1) = -682.007568 arrayOfVariantOfDouble1(2) = -29.914585` `Corresponding normal vector` `arrayOfVariantOfDouble1(3) = -0.006795 arrayOfVariantOfDouble1(4) = -0.173679 arrayOfVariantOfDouble1(5) = 0.984779`
	`document1.SaveAs "./Product1_THICKNESS.cgr" productDocument1.Activate productDocument1.Activate End Sub`	Gives the location of the cgr file you saved.
	Note: From V5R11, the calculation changes: offset1 and offset2 values make the selected surface move to two opposite directions (i.e. two positive values equal to 2mn will result in a thickness of 4mm).
	Open the ThickR11.CATScript document to access a V5R11 thickness macro (taking in account this behavioral change)
	Open the SilhouetteMacro.CATScript document from the samples folder
	`Silhouette macro example :` Dim arrayOfVariantOfDouble1(17) arrayOfVariantOfDouble1(0) = 1.000000 arrayOfVariantOfDouble1(1) = 0.000000 arrayOfVariantOfDouble1(2) = 0.000000 arrayOfVariantOfDouble1(3) = -1.000000 arrayOfVariantOfDouble1(4) = 0.000000 arrayOfVariantOfDouble1(5) = 0.000000 arrayOfVariantOfDouble1(6) = 0.000000 arrayOfVariantOfDouble1(7) = 1.000000 arrayOfVariantOfDouble1(8) = 0.000000 arrayOfVariantOfDouble1(9) = 0.000000 arrayOfVariantOfDouble1(10) = -1.000000 arrayOfVariantOfDouble1(11) = 0.000000 arrayOfVariantOfDouble1(12) = 0.000000 arrayOfVariantOfDouble1(13) = 0.000000 arrayOfVariantOfDouble1(14) = 1.000000 arrayOfVariantOfDouble1(15) = 0.000000 arrayOfVariantOfDouble1(16) = 0.000000 arrayOfVariantOfDouble1(17) = -1.000000 Dim document1 As Document Set document1 = silhouettes1.ComputeASilhouette(group1, arrayOfVariantOfDouble1, 20.000000, 0.000000)	`Coordinates of the first viewpoint vector :` `arrayOfVariantOfDouble1(0) = 1.000000 arrayOfVariantOfDouble1(1) = 0.000000 arrayOfVariantOfDouble1(2) = 0.000000` `and so on...`
